產品簡介
德國薩登原裝四沖程單缸風冷發動機,品質可靠,德國萊茵質量認證,質保3年
公司簡介
覆蓋了汽油發電機,柴油發電機,發電電焊范圍。這些產品均獲得了CE,EPA,DIRECTIVE,EC,SONCAP等多項認證。
薩登實業(上海)有限公司秉承著“以服務為理念,以誠信為宗旨,以質量為生命,以客戶為中心”的公司理念,
用嚴謹的工作態度,以持續的新品研發、工藝改良來提升自身的品牌價值及在業界的地位。
在一如既往的維護高質量產品形象的同時,薩登實業(上海)有限公司承諾向消費者和用戶提供高性價比,
品種豐富的產品系列。
展開
產品說明
數碼變頻發電機口碑品牌值得推薦
| 2KW數碼發電機 |
| 品牌 |
KINGLION |
| 型號 |
KL2000i |
| 發動機型號 |
R80-i |
| 發動機類型 |
四沖程, 頂置氣門, |
| 底置凸輪軸,單缸,直列式 |
| 排氣量 |
80cc |
| 缸徑(mm) |
48.6x43 |
| 壓縮比 |
8.8±0.2:1 |
| 額定轉數 |
4800轉/分 |
| 點火系統 |
|
| 啟動系統 |
手拉啟動 |
| 火花塞 |
TORCH A5RTC |
| 油箱容量 |
1.06加侖(4L) |
| 燃料 |
無鉛汽油 |
| 機油容量 |
0.45L |
| 機油 |
SF或更高等級 |
| SAE 5W-30,5W-40(CC級以上) |
| 額定頻率 |
50Hz |
| 額定電壓 |
220V |
| 額定交流電輸出 |
1,800W |
| zui大交流電輸出 |
2,200W |
| 直流輸出 |
12V 8.3A |
| 總諧波失真 |
≤3% |
| 負荷功率因素 |
1 |
| 頻率穩定度 |
±0.1Hz |
| 電壓穩定度 |
±4V |
| 噪音指數 |
54分貝(7m) |
| 70%功率下 |
6.0h |
| 一箱油持續運行時間 |
| 凈重/毛重 (kg) |
21/23.5 |
| 機器尺寸 (mm) |
498×290×459 |
| 標配功能 |
多臺并聯使用、市電并網使用 |
| 選配功能 |
USB輸出、電壓定制、點煙器、照明燈 |
In order analyze the inter-harmonic affections on voltage fluctuations and flickers, the
relationship between the inter-harmonics and voltage fluctuations analysis are carried out.
In order to be able to accurately determine the level of inter-harmonics to make the electric
light flicker, interharmonic-flicker limit curve drawing method based on the voltage flicker
constraints is established. The interharmonic-flicker experimental platform is built by
analog tester flicker and inter-harmonic detection device
,
and the limit curve can be drawn
through the experimental data. The 2 kinds of harmonic-flicker limit curves for the 220 V
